Full Automatic Brinell Hardness Tester/Brinell Hardness Scales
Model No. 900-357
Features
- Load Cell driven system provides precise control of test force application
- Direct Touch Screen Controls
- Engineered to obtain highly sensitive and accurate readings
AUTOMATIC BRINELL HARDNESS TESTER
Model No. 900-357
Model 900-357 Scales HBW2.5/31.25、HBW2.5/62.5、HBW2.5/187.5、HBW5/62.5 HBW5/125、
HBW5/250、HBW5/750 HBW10/100 HBW10/250 HBW10/500、
HBW10/1000 HBW10/1500 HBW10/3000Test Force (Class 11) 31.25kgf(306.5N) 62.5kgf(612.9N) 100kgf(980.7N)
125kgf(1226N) 187.5kgf(1839N) 250kgf(2452N)
500kgf(4903N) 750kgf(7355N) 1000kgf(8907N)
1500kgf(14710N) 3000kgf(29420N)Hardness read Automatic measurement Conversion of hardness values in units Automatic Conversion: Vickers, Rockwell Screen 12-inch display Loading process Real-time display loading process, loading time “8s.” Load control Automatic (load / hold / unload) Work stations Five stations, can be equipped with 2 objectives, 3 pressure head Up and down Automatic lifting, click lifting, one-button test Focus Automatic Focus, no manual lifting screw focus Turret Automatic rotating tower, pressure head with the objective
automatically rotatingMaximum height of specimen 330mm Pressure head-outer wall distance 170mm Objective 1X, 2X Eyepiece 20X Total magnification 20X, 40X Hardness resolution 0.1HBW Time of charge 1–99s Hardness test range 3.18~653HBW Implementation standards EN ISO 6506, ASTM E-10-08, GB/T231.2, JJG150-2005 Data output Optional connection printer print report Power supply AC220+5%, 50~60Hz External dimension 595 × 245 × 1000mm Weight 300lbs Innovative closed-loop technology. The Brinell hardness tester incorporates the latest load cell technology. The test load is applied via a closed-loop control unit with a load cell, a DC motor and an electronic measurement and control unit. The result is highly accurate Brinell hardness measurements at all test loads up to 0.5%. The common load overshoot or undershoot as known from traditional dead weight, or open-loop, systems is eliminated. The absence of mechanical weights not only eliminates friction problems but also makes the Brinell Hardness Tester less sensitive to misalignments caused by vibrations.
