3 Pcs Indexable Countersink Sets for Metalworking, with TiN Coated Carbide Inserts


Degrees: 82 Degree (0046-0982)
Price:
$138.00

Shipping calculated at checkout

Stock:
In stock

California Proposition 65 Warning

Payment & Security

Payment methods

American Express Apple Pay Diners Club Discover Google Pay Mastercard PayPal Shop Pay Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.


Security

Estimate shipping

Description


  • A positive rake makes for smooth cutting without chatter.
  • Carbide indexable.
  • No tool resharpening is needed.
  • Comes with inserts.
  • 3pcs/set: 1/4", 1/2", 1-1/4"
  • The carbide inserts are 1/4"-3/4" x 1/2"shank TCMT32.51 triangle inserts; 1/2" - 1-3/4" x 1/2"shank, SCMT431 suqare imnserts; 1-1/4" - 2-1/4" x 3/4"shank, SCMT431 square insert

A countersink is a cutter used to cut a conical hole into a manufactured object. It is commonly used to allow the head of a countersunk bolt, screw, or rivet, when placed in the holes, to sit flush with or below the surface of the surrounding material (by comparison, a counterbore makes a flat-bottomed hole that might be used with a socket-head capscrew). A countersink may also be used to remove the burr left from a drilling or tapping operation hence improving the finish of the product and removing any hazardous sharp edges. Countersinking is done to make the flat head screws sit flush to the workpiece.

Each of the indexable countersinks comes with a TiN coated carbide insert. They are TCMT32.51 triangle inserts and SCMT431 square inserts. When a cutting edge becomes dull, you just need to rotate the insert in the holder to use the sharp edge. When you buy the replacement inserts, be noted that the larger nose angles and larger tip radii enable a stronger cutting edge, but they result in increased vibration and a rougher finish.

Using the indexable countersinks with carbide inserts in the production environment, you can renew the cutting edge without removing the cutting tool by simply unclamping the insert and turning it (indexing) to a fresh cutting edge or removing the completely worn insert with a new one.

Item # Angle
0046-0960 60°
0046-0982 82°
0046-0990 90°
